Unmanned Automated EV Fire Suppression System
Ceiling-mounted system that deploys an immersion tank and fire blanket automatically.
Installed on the ceiling of indoor parking lots, the A10S automatically suppresses fires caused by electric vehicles and can be remotely controlled to prevent fire spread.
When heat and smoke are detected, the connected sprinkler sprays water onto the vehicle while the immersion tank and fire blanket deploy automatically, blocking oxygen, flames and smoke and submerging the battery.
Multi-defence system that requires no firefighters on site.
Deploys and submerges the battery to a water level of 45 cm.
Resolves sprinkler spray and parking-lot illumination issues.
Slim design installs where ceilings are as low as 2,100 mm.
Mounts on the ceiling with 4 eyebolts, with no loss of parking space.
Suppression can be triggered automatically or remotely without on-site access.
| Model | A10S |
|---|---|
| Material | Aluminium |
| Size | 2,300 × 5,500 × 320 mm |
| Weight | Approx. 130 kg |
| Applicable vehicles | Sedan, SUV, RV |
| Options | Fire blanket, sprinkler, remote system |
| Step | Action |
|---|---|
| 1 | Fire occurrence → sprinkler activation onto the vehicle |
| 2 | Automatic deployment of immersion tank and fire blanket |
| 3 | Submersion of vehicle and battery; oxygen, flame and smoke blocked |
| 4 | Automatic or remote fire suppression |
See A10S in the context of the full ELEKTIGER EV Fire range — EV fire blankets · underbody nozzles · SEESAW · immersion tanks · A10S · ESS.
Parking-lot underbody nozzle with built-in flame detector for unmanned initial response.
Fire blanket and immersion tank in one — set up by one person in under a minute.
Custom-built sensors and devices that prevent fire spread in ESS and battery facilities.
Request a quotation, datasheet or test documentation. Our global sales team will respond within one business day.
